JGSM-06 YASKAWA servo controller

Description

Yaskawa Electric JGSM-06 Servo Controller

Product Description

Yaskawa JGSM-06 is a∑-7 series AC servo controller(or driver).It is used in conjunction with JGSM-06 servo motor to form a complete servo system.The servo controller receives instructions from the upper control system(such as PLC)and controls the servo motor to operate accurately.The∑-7 series is a new generation servo system launched by Yaskawa Electric,which has significantly improved performance,functionality,and usability compared to the previous generation product.

JGSM-06 YASKAWA

Product parameters

Product Name:Servo Controller(or Driver)

model:JGSM-06

Series:Σ-7(Sigma-7)

Manufacturer:Yaskawa Electric

Input voltage:200V/400V(choose according to actual application)

Control methods:position control,speed control,torque control

Communication interfaces:EtherCAT,MECHATROLINK-III,Modbus RTU,etc.(depending on specific models and configurations)

Encoder feedback:Receive encoder feedback signals from servo motors

Protection functions:overcurrent,overvoltage,overheating,short circuit,etc

Working temperature:usually between 0°C and 55°C

Product specifications

Installation method:usually rack mounted or wall mounted

series

The JGSM-06 servo controller belongs to the Yaskawa∑-7(Sigma-7)series servo system.The∑-7 series is a high-performance servo system launched by Yaskawa Electric,which has the following characteristics:

Higher performance:faster response speed,higher accuracy.

Stronger features:Supports more advanced control algorithms.

More user-friendly:easier to debug and maintain.

JGSM-06 YASKAWA

Product Features

High performance:High precision,high speed response,achieving precise control.

High efficiency:Energy saving,reducing operating costs.

High reliability:Industrial grade design ensures long-term stable operation.

Easy to use:convenient for installation,debugging,and maintenance.

Multiple control modes:Supports position control,speed control,torque control,and other control modes.

Rich functionality:Supports various advanced control functions,such as PID control,feedforward control,etc.

Strong communication capability:Supports multiple communication protocols,facilitating communication with other devices.

Product function

The main function of JGSM-06 servo controller is to:

Receive control instructions:Receive control instructions from the upper control system(such as PLC).

Control servo motor:Accurately control the motion of the servo motor according to control instructions,including position,speed,and torque.

Feedback monitoring:Receive encoder feedback signals from servo motors and monitor the motor’s operating status in real-time.

Protect motor:Provide various protection functions to prevent motor damage.

Product Usage

JGSM-06 servo controller is widely used in various automation equipment,such as:

Numerical Control Machine Tool:Control the movement of cutting tools.

Robots:Control the movement of joints.

Automated production line:controlling the movement of various actuators.

Packaging machinery:controls the moving parts during the packaging process.

Printing machinery:controls the movement of printing rollers.

JGSM-06 YASKAWA

application area

JGSM-06 servo controller is suitable for various industrial applications that require precise control,such as:

manufacturing

robot

automation

packing

printing

spin
