Relevant information about 5SHY5045L0020 AC10272001R0101 5SXE08-0167 ABB IGCT module:
Product Description
5SHY5045L0020 AC10272001R0101 5SXE08-0167 is an IGCT(Integrated Gate Commutated Thyristor)module produced by ABB.It combines the high voltage and high current processing capabilities of thyristors with the fast switching characteristics of transistors,enabling efficient energy conversion and control in high voltage and high current power electronics applications.
5SHY5045L0020 AC10272001R0101 5SXE08-0167 ABB
Product parameters and specifications
Model:5SHY5045L0020 AC10272001R0101 5SXE08-0167
manufacturer:ABB
Voltage level:3.3kV,4.5kV and other medium and high voltage systems
Current capacity:capable of reaching rated currents of 2000A-3000A or even higher
Switching frequency:up to around 100Hz-500Hz
On state voltage drop:generally within the range of 1.5V-2.5V
Off time:usually between 20μs and 50μs
series
It belongs to ABB’s IGCT series products.
features
High power processing capability:capable of withstanding high voltage and passing large currents,meeting the needs of high-power power electronic devices.
Fast switching characteristics:Fast switching speed,can quickly achieve conduction and disconnection,improve the dynamic response speed and operating efficiency of the system.
Low loss:The conduction loss and turn off loss are relatively low,which helps to improve the energy utilization efficiency of the system and reduce heat generation.
High reliability:Adopting advanced technology and strict quality control,it has strong anti-interference ability and stability,and can work stably for a long time in harsh industrial environments.
High integration:Integrating multiple functional circuits into a compact structure reduces the size and complexity of the system,making it easy to install and maintain.
5SHY5045L0020 AC10272001R0101 5SXE08-0167 ABB
effect
Power Conversion:Achieving efficient power conversion between AC and DC,such as converting AC to DC in a rectifier and DC to AC in an inverter.
Power control:Accurately control the voltage,current magnitude,and waveform in the circuit to meet the requirements of different loads for power and improve power quality.
System protection:It has protection functions such as overcurrent,overvoltage,undervoltage,and overheating.When the system encounters abnormalities,it can be shut down in a timely manner to protect other devices from damage.
purpose
Used for frequency converters:As the core component of medium and high voltage frequency converters,it controls the speed of the motor to flexibly adjust the speed according to the load requirements,achieving the purpose of energy saving and precise control.
Used for inverters:In inverters for high-voltage direct current transmission,flexible alternating current transmission and other systems,efficient power transmission and flexible transformation are achieved.
5SHY5045L0020 AC10272001R0101 5SXE08-0167 ABB
application area
Power system:used for high-voltage direct current transmission,flexible alternating current transmission system(FACTS),etc.,to achieve long-distance transmission and flexible control of large capacity power,improve power system stability and transmission efficiency.
In the industrial field,it is used as a drive system for large motors such as steel mills,mine hoists,cement mixers,etc.in metallurgy,mining,cement and other industries,to achieve energy-saving operation and precise control of motors.
New energy power generation:In the inverters of wind and solar power generation,the direct current generated by power generation is converted into alternating current and integrated into the power grid or supplied to local loads,improving the efficiency and stability of new energy power generation.
Rail transit:a traction system applied to high-speed trains and urban rail transit,providing suitable power for train traction motors to achieve speed regulation and operation control of trains.
Industrial power supply:used in industrial equipment such as electroplating,electrolysis,welding,etc.that require high-power DC power supply,to convert AC power into stable DC power.
