5SHY4045L0006 3BHB030310R0001 3BHE039203R0101 GVC736CE101 5SXE12-0184 ABB IGCT module related information:
Product Description
The 5SHY4045L0006 3BHB030310R0001 3BHE039203R0101 GVC736CE101 5SXE12-0184 ABB IGCT module is an integrated gate commutated thyristor module that highly integrates the GTO chip with anti parallel diodes and gate drive circuits.It exhibits low loss characteristics of the thyristor when conducting and stable turn off capability of the transistor when turning off,achieving efficient power conversion and control.
5SHY4045L0006 3BHB030310R0001 3BHE039203R0101 GVC736CE101 5SXE12-0184 ABB
Product parameters and specifications
Model:5SHY4045L0006 3BHB030310R0001
manufacturer:ABB
Voltage parameters:3.3kV,4.5kV,etc
Current parameters:rated current of 2500A,3000A and above
On state voltage drop:usually around 1.5V-2.5V
Installation method:bolt fastening or slot type installation is commonly used
Pin configuration:having a specific number and specification of pins
series
It belongs to ABB’s IGCT series products.
features
High power processing capability:capable of withstanding high voltage and passing high current,suitable for the application needs of high-power power electronic devices.
Fast switching characteristics:Fast switching speed,able to quickly achieve conduction and disconnection,improving the dynamic response speed and operating efficiency of the system.
Low loss:Both conduction loss and turn off loss are relatively low,which helps to improve the energy utilization efficiency of the system and reduce heat generation.
High reliability:Adopting advanced technology and strict quality control,it has strong anti-interference ability and stability,and can work stably for a long time in harsh industrial environments.
High integration:Integrating multiple functional circuits into a compact structure reduces the size and complexity of the system,making it easy to install and maintain.
5SHY4045L0006 3BHB030310R0001 3BHE039203R0101 GVC736CE101 5SXE12-0184 ABB
effect
Power Conversion:Achieving efficient power conversion between AC and DC,such as converting AC to DC in a rectifier and DC to AC in an inverter.
Power control:Accurately control the voltage,current magnitude,and waveform in the circuit to meet the requirements of different loads for power and improve power quality.
System protection:It has protection functions such as overcurrent,overvoltage,undervoltage,and overheating.When the system encounters abnormalities,it can be shut down in a timely manner to protect other devices from damage.
purpose
Used for frequency converters:As the core component of medium and high voltage frequency converters,it controls the speed of the motor to flexibly adjust the speed according to the load requirements,achieving the purpose of energy saving and precise control.
Used for inverters:In inverters for high-voltage direct current transmission,flexible alternating current transmission and other systems,efficient power transmission and flexible transformation are achieved.
5SHY4045L0006 3BHB030310R0001 3BHE039203R0101 GVC736CE101 5SXE12-0184 ABB
application area
Power system:used for high-voltage direct current transmission,flexible alternating current transmission system(FACTS),etc.,to achieve long-distance transmission and flexible control of large capacity power,improve power system stability and transmission efficiency.
In the industrial field,it is used as a drive system for large motors such as steel mills,mine hoists,cement mixers,etc.in metallurgy,mining,cement and other industries,to achieve energy-saving operation and precise control of motors.
New energy power generation:In the inverters of wind and solar power generation,the direct current generated by power generation is converted into alternating current and integrated into the power grid or supplied to local loads,improving the efficiency and stability of new energy power generation.
Rail transit:a traction system applied to high-speed trains and urban rail transit,providing suitable power for train traction motors to achieve speed regulation and operation control of trains.
Industrial power supply:used in industrial equipment such as electroplating,electrolysis,welding,etc.that require high-power DC power supply,to convert AC power into stable DC power.
